Noctua consistently demonstrates that it has a clear plan for its products. This plan doesn't just involve new coolers but also improving existing products that still make sense in the market. One such cooler is the NH-L12, which has been upgraded to the L12Sx77. The upgrade includes an increase in the height of the cooler, improving compatibility with various RAM modules. Noctua has also managed to increase the number of heat pipes in this cooler, thereby enhancing its cooling performance.
Noctua NH-L12Sx77 - Introduction, specifications
The cooler itself is quite small, reaching a height of only 77mm. Even this slight increase (compared to its predecessor, the L12S) of 7mm has contributed to creating a space of 44mm under the cooler, thereby increasing compatibility with tall RAM modules. The packaging is therefore quite compact but includes everything you are accustomed to from Noctua (from thermal paste to a screwdriver...).
Specification
|
Dimensions of heatsink (with fans)
|
77x128x131 mm (H x W x D) |
|
Weight (without fan)
|
- |
|
Weight (with fans)
|
520g |
|
Fin material
|
hliník |
|
Heatpipes
|
6x |
|
Heatpipe material
|
meď |
|
Base
|
meď |
|
Fan
|
1x 120mm
|
|
Rozmery ventilátorov
|
120x120x15
|
|
Fan speeds
|
450-1850RPM +/- 10%
|
|
Maximum airflow
|
94,2 m3/h
|
|
Noise level
|
max 23,9 dBA
|
|
Maximum static pressure
|
-
|
|
Fan bearings
|
SSO2 |
|
Fan connector
|
4pin PWM |
|
Maximum TDP
|
- |
|
Compatibility
|
Intel
LGA 1851/1700/1200/115X
AMD
AM4, AM5
|
|
Price
|
84,9 EUR |
